Truck Oil Hose

Fuel oil hose Construction

· Tube: Fuel and Oil Resistant NBR rubber compound

· Reinforcement: Synthetic textile yarns

· Cover: Abrasion and weathering resistant NBR+PVC rubber compound

Fuel oil hose product line

· Pure NBR rubber hose without reinforcement

· NBR rubber hose with synthetic yarns reinforcement

· NBR rubber hose with outer braided cover

· NBR rubber with cloth surface for high duty air transfer

Fuel oil hose Application

· All NBR rubber hose can be applied for transmitting gasoline, ethanol gasoline ,diesel ,and lubrication oil in automobile,motorcycle and combustion engine

Fuel oil Specification

Inside Diameter		Outside Diameter(mm)	Reinforced Layer(B)	Burst pressure (MPa)	Length Max.(m)	Weight(kg/m)	Working pressure (MPa)
inch	mm	Outside Diameter(mm)	Reinforced Layer(B)	Burst pressure (MPa)	Length Max.(m)	Weight(kg/m)	Working pressure (MPa)
3/16	5	12	1	3.0~6.0	100	0.15	1~2.0
1/4	6	13	1	3.0~6.0	100	0.17	1~2.0
5/16	8	15	1	3.0~6.0	100	0.22	1~2.0
3/8	10	17	1	3.0~6.0	100	0.25	1~2.0
1/2	13	21~22	1~2	3.0~6.0	100	0.39~0.45	1~2.0
5/8	16	24~25	1~2	3.0~6.0	100	0.44~0.60	1~2.0
3/4	19	28~29	1~2	3.0~6.0	100	0.65~0.70	1~2.0
1	25	35~36	1~2	3.0~6.0	50	0.86~0.96	1~2.0
